Tower Parts List
Machine
Section
HLI Part
Number
Item Description
Qty
1
500133
500317
TOWER - STD
TOWER - 110
1
1
2
300038
ELEVATOR UNIT MOTOR VP3310D
1
3
200091
SCREW M8x20L & S.W.
4
4
200090
SCREW M10x25L & S.W. & W.
5
5
300030
ELEVATOR UNIT SPEED REDUCER VTM-40
1
6
200085
SCREW M8x25L & S.W. & W.
4
7
500135
CHANNEL SUPPORT
2
8
200078
SCREW M6x16L & S.W. & W.
4
9
500136
500290
CHAIN WHEEL COVER - STD
CHAIN WHEEL COVER - 110
1
1
10
500041
UP & DOWN CHAIN WHEEL (LOWER) 11 TEETH
1
11
200802
SHCS, M6 x 16L & S.W & W
1
12
300020
BEARING 6202-2NR
1
13
500102
SPEED REDUCER BEARING SEAT
1
14
200099
SCREW M4x6L & W.
2
15
200120
SCREW M6x8L
1
16
300000
PIN ø4X8
1
17
200082
SCREW M8x12L
2
18
500103
BEARING ADJUST SEAT
1
19
200077
SCREW M6x12L & W.
4
20
500003
UPPER CHAIN WHEEL SHAFT
1
21
300017
BEARING 6002ZZ
2
22
500118
UPPER CHAIN WHEEL
1
23
500093
RING
2
24
300008
RING STW-15
2
25
500104
ADJUST BAR WASHER
1
26
200140
NUT M12
1
27
300049
500488
CHAIN - STD
CHAIN - 110
1
1
28
500025
ELEVATOR UNIT CHAIN SCREW SHAFT
2
29
200147
WASHER M12
4
30
500092
CHAIN ADJUST SEAT
1
