Section 4 - Operating the Bale Mover
LOADING BALES IN THE FIELD
Tractor Cab Controller
1. In the loading modes, the Control Switch
in the tractor cab enables the hydraulic
remotes to control the bale lift arms and
the bale roller chains.
- Hang the switch in a convenient
location in the tractor cab. Use the top
hook to secure it.
2. Loading bales on the right side
- Move the rocker switch to the right
position.
- One tractor remote will be used to
lift the bales into position onto the
right side of the deck.
- The other tractor remote will be
used to push the bale back on the
right deck once it is in position.
3. Loading bales on the left side
- Move the rocker switch to the left
position.
- One tractor remote will be used to
lift the bales into position onto the
left side of the deck.
- The other tractor remote will be
used to push the bale back on the
left deck once it is in position.
Left Side Loading
211053
Right Side Loading
211052
Page 4-3
