Section 4 - Operating the Bale Mover
4. Drive up to the bale and position the lift
arm forks so that it can lift the bale.
- It is not required to stop to pick up a
bale.
- Continue driving forward.
5. The lift arm can rotate a bale somewhat
to align it into the lift arm.
6. Drive forward until the lift arm forks are
fully under the bale.
Drive Up to Bale with Arm Lowered
211013
Bale Can Be Rotated Some by the Lift Arm
211016
Drive Forward Until Fork Under Bale
211029
Page 4-4
