Section 4 - Operating the Mower
Page 4-6
13. Crossing Ditches and Steep Inclines
- Cross ditches or inclines at about a
30° approach angle.
- Maintain sufficient height to prevent
blades from hitting the ground.
- Do not approach a ditch or steep
incline straight on as this may collapse
the driveline to its shortest length,
causing damage by pushing the PTO
into the tractor or into the drivebox on
the hitch arm or downward onto the
PTO shaft, breaking it off.
14. Wing Cutting Angles
- Do not operate the wing driveline at
angles greater than 25° down or 55°
up to prevent damage to the
drivelines.
15. Making Turns
- Do not exceed 90° on driveline while
turning to avoid damage to the front
hitch frame pivot.
Driveline Collapsed in Steep Incline
107089C
Cross Ditch at 30° Angle
107072
Cutting Angles
107088C
