Thermal Imager User Manual
6
Figure 2-2 Thermal Imager with a Focus Ring
Focusing adjustment is ONLY supported by the imager with a focus ring.
Image Rotation
Tap to rotate live image by 90 degrees.
SuperIR
Switch on to get an enhanced thermal image.
2.1.3 Thermal Image Calibration
For temperature measurement accuracy and image effect, it is
recommended to conduct image calibration. It is common to have brief
image freeze during image calibration.
Auto Calibration
In this mode, the imager automatically calibrates images according to its
internal rules.
Tap to enable Auto Calibration. Tap it again to turn off the function.
Manual Calibration
Tap to calibrate the image for one time.
It is recommended to enable Auto Calibration. Otherwise, you need
conduct Manual Calibration from time to time for the accuracy of thermal
imaging and temperature measurement.
