User Manual of HD-TVI Speed Dome
© Hikvision
12
Chapter 3 Menu Operation
 The operation interface of the different speed domes may differ. Please refer to the actual
operation interface.
 You can click the left and right direction buttons in the PTZ control panel via the web browser of
the DVR to enter the next page or return to the previous page of the submenu if more than one
page is available.
MAIN MENUS
DOME
SETTINGS
SYSTEM
INFO
ADDRESS
COM
FORMAT
PROTOCOL
FIRMWARE
HARDWARE
BUILD DATE
TEMPERATURE
SYSTEM
SETTINGS
CAMERA
SETTINGS
MOTION
SETTINGS
PRESETS
PATROLS
TIMING
TASKS
PATTERNS
PRIVACY
MASK
ALARM
INPUT
ALARM
OUTPUT
ZONES
RESTORE
SETTINGS
RESTORE
CAMERA
REBOOT
DOME
LANGUAGE
CAM
VERSION
PARAM
DATE
VIDEO
SETTINGS
IR SETTINGS
Figure 3-1 Menu Structure
Before you start:
You can operate the speed dome using the on-screen display menu remotely by connecting to a
DVR or a DVS (encoder).
Examples of entering speed dome menu are listed as follows:
 Enter the menu by pressing buttons: PTZ -> REC -> 9 -> 5 on the front panel of the DVR.
 Enter the menu by pressing buttons: CALL -> 9 -> 5 -> ENTER on the keyboard.
 Enter the menu via the web browser of a DVR/DVS.
Menu operations via the web browser of a DVR will be taken as an example in this chapter.

HIKVISION DS-2AE7230TI-A Specifications

General

Type	CCTV security camera
PTZ control	Yes
Languages support	CHI (SIMPL), ENG
Number of languages	2
Placement supported	Outdoor
Connectivity technology	Wired
Maximum operating distance	120 m
Pan range	0 - 360 °
Pan speed	240 °/sec
White balance	ATW, Auto, Indoor, Manual, Outdoor
Tilt angle range	-15 - 90 °
Camera shutter speed	PAL: 1-1/10000s, NTSC: 1-1/10000s s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Effective sensor resolution	1920 pixels
Interface	BNC
AC input voltage	24 V
Power consumption (max)	30 W
Power over Ethernet (PoE)	No
Form factor	Dome
Mounting type	Desk/Wall
Product color	White
International Protection (IP) code	IP66
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	50 dB
Digital zoom	16 x
Optical zoom	30 x
Focal length range	4 - 120 mm
Maximum aperture number	4.4
Number of cameras	1
Operating temperature (T-T)	-30 - 65 °C

Weight and Dimensions

Height	353.4 mm
Weight	4500 g
Diameter	220 mm
