HIKVISION DS-2AE7230TI-A User Manual

User Manual of HD-TVI Speed Dome
© Hikvision
44
Appendix 3 24VAC Wire Gauge & Transmission Distance
The following table describes the recommended Max. distance adopted for the certain wire gauge
when the loss rate of 24VAC voltage is less than 10%. For the AC driven device, the maximum
voltage loss rate is 10% allowable. For example, for a device with the rating power of 80VA which is
installed at a distance of 35 feet (10m) away from the transformer, then 0.8000mm is required as
the minimum wire gauge.
0.8000
1.000
1.250
2.000
10
283(86)
451(137)
716(218)
1811(551)
20
141(42)
225(68)
358(109)
905(275)
30
94(28)
150(45)
238(72)
603(183)
40
70(21)
112(34)
179(54)
452(137)
50
56(17)
90(27)
143(43)
362(110)
60
47(14)
75(22)
119(36)
301(91)
70
40(12)
64(19)
102(31)
258(78)
80
35(10)
56(17)
89(27)
226(68)
90
31(9)
50(15)
79(24)
201(61)
100
28(8)
45(13)
71(21)
181(55)
110
25(7)
41(12)
65(19)
164(49)
120
23(7)
37(11)
59(17)
150(45)
130
21(6)
34(10)
55(16)
139(42)
140
20(6)
32(9)
51(15)
129(39)
150
18(5)
30(9)
47(14)
120(36)
160
17(5)
28(8)
44(13)
113(34)
170
16(4)
26(7)
42(12)
106(32)
180
15(4)
25(7)
39(11)
100(30)
190
14(4)
23(7)
37(11)
95(28)
200
14(4)
22(6)
35(10)
90(27)
Distance
(feet)
Power (va)
Wire Gauge
(mm)

HIKVISION DS-2AE7230TI-A Specifications

General

Type	CCTV security camera
PTZ control	Yes
Languages support	CHI (SIMPL), ENG
Number of languages	2
Placement supported	Outdoor
Connectivity technology	Wired
Maximum operating distance	120 m
Pan range	0 - 360 °
Pan speed	240 °/sec
White balance	ATW, Auto, Indoor, Manual, Outdoor
Tilt angle range	-15 - 90 °
Camera shutter speed	PAL: 1-1/10000s, NTSC: 1-1/10000s s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Effective sensor resolution	1920 pixels
Interface	BNC
AC input voltage	24 V
Power consumption (max)	30 W
Power over Ethernet (PoE)	No
Form factor	Dome
Mounting type	Desk/Wall
Product color	White
International Protection (IP) code	IP66
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	50 dB
Digital zoom	16 x
Optical zoom	30 x
Focal length range	4 - 120 mm
Maximum aperture number	4.4
Number of cameras	1
Operating temperature (T-T)	-30 - 65 °C

Weight and Dimensions

Height	353.4 mm
Weight	4500 g
Diameter	220 mm
