User Manual of HD-TVI Speed Dome
© Hikvision
29
3.4.2 Configuring Presets
Purpose:
A preset is a user-defined monitoring position/point. You can simply call the preset number to
change the monitor scene to the defined position.
Steps:
1. Move the cursor to enter preset configuration submenu:
MAIN MENU > DOME SETTINGS > PRESETS
PRESETS
PRESET NO. 1
<UNDEFINED>
SET PRESET
CLEAR
BACK EXIT
Figure 3-12 Preset Configuration Menu
2. Choose the preset number:
Move the cursor to PRESET NO. and click IRIS+ to enter. Click the up and down buttons to
choose the preset number which needs to be edited. If the preset has been defined, the preset
label will be listed under the number; if it has not been defined, you will see the information
UNDEFINED under the number.
 There are up to 255 presets can be set for the speed dome.
 The system-defined presets will be displayed on this submenu and they are not editable.
3. Set the preset position.
Move the cursor to PRESET PTZ and click IRIS+ to edit the preset position. Use the direction
buttons to move the speed dome to find the desired scene/position, and then press IRIS+ to
confirm the settings and return to the previous menu, or press IRIS- to cancel.
The preset position settings will be restricted by the limits if they are defined.
4. Call the presets.
You can select the preset number from the drop-down preset list in the control panel of the
encoder through a web browser, and click the arrow to call a user-defined or system-defined
preset.
5. Clear the preset settings.
Move the cursor to CLEAR and click IRIS+ to clear the settings of the current preset.

HIKVISION DS-2AE7230TI-A Specifications

General

Type	CCTV security camera
PTZ control	Yes
Languages support	CHI (SIMPL), ENG
Number of languages	2
Placement supported	Outdoor
Connectivity technology	Wired
Maximum operating distance	120 m
Pan range	0 - 360 °
Pan speed	240 °/sec
White balance	ATW, Auto, Indoor, Manual, Outdoor
Tilt angle range	-15 - 90 °
Camera shutter speed	PAL: 1-1/10000s, NTSC: 1-1/10000s s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Effective sensor resolution	1920 pixels
Interface	BNC
AC input voltage	24 V
Power consumption (max)	30 W
Power over Ethernet (PoE)	No
Form factor	Dome
Mounting type	Desk/Wall
Product color	White
International Protection (IP) code	IP66
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	50 dB
Digital zoom	16 x
Optical zoom	30 x
Focal length range	4 - 120 mm
Maximum aperture number	4.4
Number of cameras	1
Operating temperature (T-T)	-30 - 65 °C

Weight and Dimensions

Height	353.4 mm
Weight	4500 g
Diameter	220 mm
