User Manual of HD-TVI Speed Dome
© Hikvision
36
Move the cursor to CLEAR ZONE, click IRIS+ to clear all the settings of the current zone, and click
IRIS+ again to confirm the settings and exit.
3.5 Configuring and Handling Alarms
The alarm related function is supported by the 5-inch IR speed dome only.
3.5.1 Configuring Alarm Input and Linkage Actions
Purpose:
This section explains how to configure the speed dome to respond to alarm events with alarm
linked actions, such as calling presets, patrols, patterns, scanning, etc.
Steps:
1. Move the cursor to enter the alarm configuration submenu:
MAIN MENUS > DOME SETTINGS > ALARM INPUT
ALARM INPUT
RESUME ON
SEQUENCE 5
DELAY TIME 5
ALARM SETTING
BACK EXIT
ALARM SETTING
ALARM NO. 1
PRIORITY HIGH
LINKAGE NONE
ALARM OUTPUT NONE
ALARM INPUT OPEN
BACK EXIT
Figure 3-20 Alarm Configuration Menu
2. Choose the alarm number.
Steps:
(1) Move the cursor to ALARM NO. and click the IRIS+ to enter edit mode.
(2) Click the up and down direction buttons to select the number of the alarm which is to be
configured.
(3) Click IRIS+ again to confirm and exit edit mode of this column.
You can configure up to 2 alarm inputs.
3. Move the cursor to ALARM SETTING and click the IRIS+ to enter the setting alarm submenu.
4. Configure the alarm input.
Steps:
(1) Move the cursor to ALARM INPUT and click the IRIS+ to enter edit mode.
(2) Click the up and down direction buttons to set the input status. You can configure it as OPEN
(Normally open), CLOSE (Normally closed) or OFF (disable the alarm input).

HIKVISION DS-2AE7230TI-A Specifications

General

Type	CCTV security camera
PTZ control	Yes
Languages support	CHI (SIMPL), ENG
Number of languages	2
Placement supported	Outdoor
Connectivity technology	Wired
Maximum operating distance	120 m
Pan range	0 - 360 °
Pan speed	240 °/sec
White balance	ATW, Auto, Indoor, Manual, Outdoor
Tilt angle range	-15 - 90 °
Camera shutter speed	PAL: 1-1/10000s, NTSC: 1-1/10000s s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Effective sensor resolution	1920 pixels
Interface	BNC
AC input voltage	24 V
Power consumption (max)	30 W
Power over Ethernet (PoE)	No
Form factor	Dome
Mounting type	Desk/Wall
Product color	White
International Protection (IP) code	IP66
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	50 dB
Digital zoom	16 x
Optical zoom	30 x
Focal length range	4 - 120 mm
Maximum aperture number	4.4
Number of cameras	1
Operating temperature (T-T)	-30 - 65 °C

Weight and Dimensions

Height	353.4 mm
Weight	4500 g
Diameter	220 mm
