You can set 485 CHECK as ON or AUTO for automatic RS-485 configuration diagnosis. If the
configuration is incorrect, an alert will be received; if you set the value as AUTO, it will
automatically stop the diagnosis when no errors exist.
Power Memory Settings
The dome can resume its previous PTZ status after it restarted from a power-off when it stops at a
position longer than the predefined time. You can set the memory time to 10S, 30S, 60S, 180S, and
300S.
Coaxial Control
The Coaxial transmission function can be enabled to transmit the RS485 signal along with the video
signal via the BNC cable. If the connected encoding device supports the Coaxial transmission as well,
the RS485 cable will not be necessary.
Steps:
1) Enable the Coaxial control function by setting the option of COAXIAL CONTROL to ON.
2) Select the Coaxial control protocol, there are HIK-C, PELCO-C and AUTO selectable.
The transmission protocol of the connected encoding device should be set the same as the
speed dome to support the coaxial transmission.
3.3 Configuring Image Parameters
3.3.3 Configuring Camera Parameters
Purpose:
You can set the camera parameters including focus, shutter speed, iris, etc.
Enter the camera parameters settings menu:
MAIN MENUS > DOME SETTINGS >CAMERA SETTINGS
