HIKVISION DS-2AE7230TI-A User Manual

User Manual of HD-TVI Speed Dome
© Hikvision
17
DISPLAY SETTINGS
ZOOM RATIO ON
P/T ANGLE ON
ALARM OFF
TIME ON
PRESET LABEL ON
ZONE OFF
BACK EXIT
DISPLAY SETTINGS
ADDRESS OFF
ERROR RATE OFF
FAN/HEAT OFF
BACK EXIT
Figure 3-6 Display Settings
The speed dome shows the viewing direction when you manually control it to rotate.
Table 1-1 Viewing Direction Display
Display
N
NE
E
SE
S
SW
W
NW
Indication
North
Northeast
East
Southeast
South
Southwest
West
Northwest
The north direction refers to the angle zero.
 Heat Parameter Configuration
You can set the HEAT CONTROL as TEMP (controlled by the temperature), ON or OFF.
 Fan Parameter Configuration
You can set the FAN CONTROL as TEMP (controlled by the temperature), ON or OFF.
 EIS (Electronic Image Stabilization) Configuration
You can set the EIS FUNCTION as ON or OFF; and set the EIS LEVEL as 0-3.
The selectable EIS level varies according to the different camera models.
 Preset Direct Focus
You can set the preset direct focus function ON/OF on PRESET DFOCUS submenu.
 Protocol and RS-485 settings
 Select the protocol.
Choose the protocol on PROTOCAL submenu. You can configure it as AUTO MATCH, PELCO-P,
PELCO-D, or HIKVISION. When you choose AUTO MATCH, it is protocol self-adaptive.
 Set the protocol status.
Set the PROTOCOL STATUS as ON to enable the user-defined protocol.
 Enable the RS-485 configuration diagnosis.

HIKVISION DS-2AE7230TI-A Specifications

General

Type	CCTV security camera
PTZ control	Yes
Languages support	CHI (SIMPL), ENG
Number of languages	2
Placement supported	Outdoor
Connectivity technology	Wired
Maximum operating distance	120 m
Pan range	0 - 360 °
Pan speed	240 °/sec
White balance	ATW, Auto, Indoor, Manual, Outdoor
Tilt angle range	-15 - 90 °
Camera shutter speed	PAL: 1-1/10000s, NTSC: 1-1/10000s s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Effective sensor resolution	1920 pixels
Interface	BNC
AC input voltage	24 V
Power consumption (max)	30 W
Power over Ethernet (PoE)	No
Form factor	Dome
Mounting type	Desk/Wall
Product color	White
International Protection (IP) code	IP66
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	50 dB
Digital zoom	16 x
Optical zoom	30 x
Focal length range	4 - 120 mm
Maximum aperture number	4.4
Number of cameras	1
Operating temperature (T-T)	-30 - 65 °C

Weight and Dimensions

Height	353.4 mm
Weight	4500 g
Diameter	220 mm
