User Manual of HD-TVI Speed Dome

3.4.3 Configuring Patrols

Purpose:

A patrol is a scanning track specified by a group of user-defined presets. You can call a patrol to scan

the scenes automatically among the user-defined presets in sequence.

Steps:

1. Move the cursor to enter patrol configuration submenu:

MAIN MENU > DOME SETTINGS > PATROLS

PATROLS

PATROL NO. 1

EDIT PATROL

PREVIEW

CLEAR PATROL

PATROL_D 30S

BACK EXIT

Figure 3-13 Patrol Configuration Menu

2. Choose the patrol number.

Steps:

(1) Move the cursor to PATROL NO. and click IRIS+ to enter edit mode.

(2) Click the up and down direction buttons to select the number of the patrol which is to be

configured.

(3) Click IRIS+ again to confirm the settings and exit edit mode of this column.

Up to 10 patrols can be configured.

3. Edit the patrol.

Steps:

(1) Move the cursor to EDIT PATROL and click IRIS+ to enter edit mode.

NUM PST DWELL SPEED

1 0 6 30

2 0 6 30

3 0 6 30

4 0 6 30

5 0 6 30

6 0 6 30

7 0 6 30

IRIS+ OK IRIS- CANCEL

Figure 3-14 Edit the Patrol
