HD-TVI Speed Dome DS-2AE7232TI-A User Manual
UM THD DS-2AE7232T-x 020519NA 17
2. Move the cursor to the target item and click IRIS+, and click up/down direction buttons to set each
display mode to ON or OFF, and set each display time to 2 seconds, 5 seconds, or 10 seconds.
3. Click IRIS+ button to confirm the settings.
NOTE: If you enable the OSD (On-Screen Display) for both ZOOM SHOW and P/T ANGLE, when calling a
preset, the preset no. will display on the screen until the preset scene passes.
Figure 7, Display Settings
The speed dome shows the viewing direction when you manually control and rotate it.
Table 1-1 Viewing Direction Display
NOTE: The north direction refers to the angle zero.
• Heat Parameter Configuration: You can set the HEAT CONTROL as TEMP (controlled by the temperature),
ON or OFF.
• Fan Parameter Configuration: You can set the FAN CONTROL to TEMP (controlled by the temperature), ON,
or OFF.
• EIS (Electronic Image Stabilization) Configuration: You can set the EIS FUNCTION to ON or OFF, and set the
EIS LEVEL to 0 to 3.
NOTE: The selectable EIS level varies by camera model.
• Preset Direct Focus: You can set the preset direct focus function to ON/OFF on the PRESET DFOCUS
submenu.
