Day/Night High-definition Dome Camera·User Manual
20
20
2.2.5 Indoor Wall Mounting
For the wall mounting, you have to purchase a wall mount.
Steps:
1. Align the number 2 holes of the back box with the number 1
holes of the wall mount.
2. Secure the back box to the wall mount with four screws.
Figure 2-17 Securing Back Box
3. Route the cables through the hole in the center of the wall
mount.
4. Align the camera with the back box.
5. Tighten the set screws to secure the camera with the back box.
6. Connect the video output connector to the monitor. Connect
the power connector to the power supply.
