Day/Night High-definition Dome Camera·User Manual
CAMERA ID
ABCDEFGHIJKLMNOPQRSTUV
WXYZ0123456789-!”#$%&’
()_`,¥:;<=>?@\^*.x+/
CHR1 CHR2
← → ↑ ↓ CLR POS8
RETURN8
Figure 3-15 CAMERA ID
3.13 SYNC/PIXEL CORRECT Setting
Both internal and line lock synchronization are available. (Only the
camera which supports DC 12 V and AC 24 V power has line lock
synchronization.)
If 12V DC power supply is applied, SYNC mode is internal
synchronization and not adjustable.
If 24V AC power supply is applied, you can select either
internal or line lock synchronization.
Press the button to right for about 2seconds, you can exchange
the SYNC mode. Then get to the menu of the SYNC setting,
you can adjust the phase of the Line-lock.
Press the button to left for about 2 seconds; you can enable
auto PIXEL CORRECT function. This function will be more
active in the absolutely dark environment. Make sure that the
lens’s IRIS is closed before using this function.
To Next Page
