Day/Night High-definition Dome Camera·User Manual
7
7
Figure 2-1 Removing the Lower Dome
4. Loosen the three screws as shown in Figure 2-2 with the
supplied screw driver.
5. Remove the camera from the back box.
Figure 2-2 Removing the Camera
2.2 Mounting
2.2.1 Ceiling Mounting
Steps:
1. Attach the drill template (supplied) to the place where you
want to fix the camera.
2. According to the circles on the drill template as shown in Figure
2-3, drill screws holes in the ceiling on your demand.
Set Screws
