To study the wireless alarms, e.g. the access control device, select Wireless
Alarm from the Study drop-down list, and select the device serial number (1-8)
from the drop-down list, and click ; and then send the signal from the
wireless alarm device to the camera.
Figure 6-37 Study the Wireless Alarm
Notes:
To study the access control device, you can open the door/separate the device to
send the signal.
Configure the Wireless Alarm and PIR Alarm
Configure the Wireless Alarm
Steps:
(1) Enter the Wireless Alarm Settings interface:
Configuration > Advanced Configuration > Events > Other Alarm
(2) Select the wireless alarm number. This camera supports up to 8 channels of
external wireless alarm input.
Figure 6-38 Wireless Alarm Settings
(3) Check the checkbox of Enable Wireless Alarm to activate the alarm and define
the alarm name in the Alarm Name field.
(4) Check the checkbox to select the linkage method taken for the wireless alarm.
Audible warning, notify surveillance center, send email, upload to FTP, trigger
channel, trigger alarm output and trigger wireless alarm output are selectable.
Please refer to Step 3 Set the Alarm Actions for Motion Detection in Section
6.6.1.
