User Manual of Network Camera

Note: DS-2CD8464F-EI(Z)(W) camera supports wireless audible and visual alarm as

the wireless alarm output for the wireless alarm. Check the check box of Wireless

audible and visual alarm to activate the alarm output.

Figure 6-39 Wireless Alarm Output

(5) Click to save the settings.

 Configure the PIR Alarm

Steps:

(1) In the Other Alarm configuration interface, check the checkbox of Enable PIR

Alarm to activate the PIR alarm and define the alarm name in the Alarm Name

field.

Figure 6-40 PIR Alarm Settings

(2) Check the checkbox to select the linkage method taken for the PIR alarm. Audible

warning, notify surveillance center, send email, upload to FTP, trigger channel,

trigger alarm output and trigger wireless alarm output are selectable. Please

refer to Step 3 Set the Alarm Actions for Motion Detection in Section 6.6.1.

Note: DS-2CD8464F-EI camera supports wireless audible and visual alarm as the

wireless alarm output for the PIR alarm. Check the check box of Wireless audible

and visual alarm to activate the alarm output.

Figure 6-41 Wireless Alarm Output

(3) Click to save the settings.

Note: The wireless alarm/PIR alarm triggered record will be started if the wireless

alarm or PIR alarm is triggered on the defined recording schedule, either when the

wireless/PIR alarm is enabled or not. Please refer to Section 7.2 for details about

configuring recording schedule.

www.cctvireland.ie

Other manuals for HIKVISION DS-2CD2012-I

Questions and Answers:

Need help?

Do you have a question about the HIKVISION DS-2CD2012-I and is the answer not in the manual?

General

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Form factor	Bullet
Product color	White
International Protection (IP) code	IP66
Total megapixels	1.3 MP
Maximum resolution	1280 x 960 pixels
Supported video modes	-
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 960, 640 x 480 (VGA), 704 x 576
Camera shutter speed	1/25(1/30) - 1/100000 s
Minimum illumination	0.01 lx
Field of view (FOV) angle	73.1 °
Sensor type	CMOS
Optical sensor size	1/3 \
Lens diameter	4 mm
Focus adjustment	2.0
Password protection type	User
LED type	IR
Night vision distance	30 m
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	+12V
Power source type	PoE
Power consumption (max)	5 W
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
