HIKVISION DS-2CD2432F-IW - Ceiling Mounting

Network Cube Camera·Quick Start Guide
19
19
Ceiling Mounting 3.3
Drill the screw holes according to the drill template. 1.
Drill Template
Screw hole All:for Mounting Base
1
1
Drill Template Figure 3-4
Disassemble the 3-axis bracket. Hold the base with one hand, 2.
and rotate the pole anticlockwise to disassemble the pole from
the base.
