5 Inch Network High-definition Speed Dome User Manual
5
Chapter 1 Brief Introduction
1.1 Description
Integrating the network remote monitoring capability with the functions of the high speed dome, the Network High Speed Dome is a
new product model which features easy installation and operation and facilitated wiring design. With built-in video server, the
Network Speed Dome is capable of providing the following new features: real-time video stream compressed and then transmitted via
network to different clients simultaneously; based on Ethernet, and analog video output supported; TI DAVINCI processing chip and
platform adopted to ensure high reliability and stability of performance; H.264 compression adopted to effectively save network
transmission bandwidth and HD storage space; dynamic configuration of encoding parameters; PPPoE, DHCP, UDP, MCAST and
TCP/IP protocols supported; bidirectional voice talk, OSD overlay and RS-485 serial port control; built-in Web Server allows control
of speed dome via IE browser; main stream and sub stream selectable for transmission; local and remote alarm response actions;
multi-zone motion detection with different sensitivity levels configurable; remote integrated storage based on IPSAN and NAS; and
watermark technology adopted for stream data to prevent unauthorized operation of the record files, etc.
The Network High-definition Speed Dome can be widely applied to various monitoring scenes such as the river, forest, road, railway,
airport, harbor, oil field, sentry, plaza, park, scenic spot, street, station, stadium, etc.
1.2 Outline
Back Box
Back Box
Dome Drive
Bubble
5 Inch Network High-definition Speed Dome
1.3 Functions
Multi-lingual OSD Menu
The dome provides multi-lingual OSD menu for display of system information and setting of dome parameters.
Self-adaptive to Multiple Protocols
The dome is compatible with PELCO-D, PELCO-P, PRIVATE-Code protocol, etc., and is capable of being self-adaptive to these
protocols without need of selecting protocol by DIP switch settings.
Keyboard Control
The pan/tilt movement and zoom actions of dome can be controlled by the control keyboard, DVR, matrix, etc.
