2.3 Rack-Mounted Installaon
Steps
1. Check the grounding and stability of the rack.
2. Use the
aached screws to x the two L-shaped brackets to the sides of the switch.
Figure 2-2 Fix L-Shaped Brackets
3. Place your switch on the rack, x it to the rack with self-prepared screws to stably install your
switch.
Figure 2-3 Fix to the Rack
100 Mbps PoE Switch Quick Start Guide
5
