3. Turn on Enable.
4. Set the
moon detecon area.
-
Click Draw Area or Clear to draw or clear areas. The rst area is set as full screen by default.
-
Click Full Screen to set the moon detecon area as full screen. You can drag on the preview
window to draw
moon detecon areas.
5. Adjust
Sensivity. Sensivity allows you to calibrate how easily movement could trigger the
alarm. A higher value results in the more readily to triggers moon detecon.
6.
Oponal: Set Target Detecon as Human or Vehicle to discard alarms which are not triggered
by human body or vehicle. Only certain camera models support this funcon.
7. Set the arming schedule. Refer to Congure Arming Schedule for details.
8. Set the linkage acons. Refer to Congure Alarm Linkage Acon for details.
9. Click Apply.
Line Crossing
Detecon
Line crossing detecon detects people, vehicles, and objects crossing a set virtual line. The
detecon direcon can be set as bidireconal, from le to right or from right to le.
Steps
1. Go to
Conguraon → Camera → Event → Line Crossing .
Figure 5-10 Line Crossing Detecon
2. Select a camera.
3. Turn on Enable.
4. Set line crossing
detecon rules and detecon areas.
1) Set Arming Area. Up to 4 arming areas are selectable.
2) Select
Direcon as A<->B, A->B, or A<-B.
A<->B
Only the arrow on the B side shows. An object crossing a congured line in both direcons
can be detected and trigger alarms.
Network Video Recorder User Manual
26

HIKVISION DS-7104NI-Q1 Specifications

General

Certification	FCC 15 B, ANSI C63.4-2014 CE EN50130-4, EN 61000-3-2, EN 61000-3-3
Product color	Black
Output current	1 A
Output voltage	48 V
Power consumption (typical)	10 W
Total Power over Ethernet (PoE) budget	36 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
HDD capacity	0 GB
HDD interface	SATA, SATA II, SATA III
Maximum storage capacity	6 TB
Number of HDDs installed	0
Number of HDDs supported	1
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	5
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Power over Ethernet (PoE) ports quantity	4
Video codecs	H.265+/H.265/ H.264+/H.264
Input bandwidth	40 Mbit/s
Output bandwidth	60 Mbit/s
Maximum resolution	1920 x 1080 pixels
Video input channels	4 channels
Supported resolutions	1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Wi-Fi	No

Weight and Dimensions

Depth	225 mm
Width	265 mm
Height	48 mm
Weight	1000 g
