18.1.7 DS-7100HQHI-F1/N
Model
DS-7104HQHI-F1
/N
DS-7108HQHI-F1
/N
DS-7116HQHI-F1/
N
Video/Audio
input
Video
compression
H.264+/H.264
Analog video
input
4-ch 8-ch 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Turbo HD
input
3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
Note: The 3 MP signal input is only available for the first channel
of DS-7104HQHI-F1/N, the first 2 channels of
DS-7108HQHI-F1/N, and the first 4 channels of
DS-7116HQHI-F1/N.
AHD input 1080p25, 1080p30, 720p25, 720p30
HDCVI input 1080p25, 1080p30, 720p25, 720p30
CVBS input Support
Audio
compression
G.711u
Audio input/
Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ) 、
Video/Audio
output
HDMI/VGA
output
1-ch, 1920 × 1080/60Hz,1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
HDMI: 1-ch, 4K
(3840 × 2160)/30Hz,
2K (2560 ×
1440)/60Hz, 1920 ×
1080/60Hz, 1280 ×
1024/60Hz, 1280 ×
720/60Hz, 1024 ×
768/60Hz
VGA: 1-ch, 2K (2560
× 1440)/60Hz, 1920
× 1080/60Hz, 1280 ×
1024/60Hz, 1280 ×
720/60Hz, 1024 ×
768/60Hz
Encoding
When 1080p Lite mode not enabled:

HIKVISION DS-7116HQHI-F1/N Specifications

General

Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Power consumption (typical)	20 W
Voltage	12 V
Product color	White
Rack capacity	1U
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Video input channels	16 channels
USB 2.0 ports quantity	2
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	1200 g
Dimensions (WxDxH)	285 x 210 x 45 mm
