HIKVISION DS-7116HQHI-F1/N User Manual

Digital Video Recorder User Manual
285
18.1.9 DS-7200HQHI-F2/N
Model DS-7208HQHI-F2/N DS-7216HQHI-F2/N
Video/Audio
input
Video
compression
H.264+/H.264
Analog video
input
8-ch 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron
connection
Turbo HD input
3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
Note: The 3 MP signal input is only available for the first 2
channels of DS-7208HQHI-F2/N, and the first 4 channels of
DS-7216HQHI-F2/N.
AHD input 1080p25, 1080p30, 720p25, 720p30
HDCVI input 1080p25, 1080p30, 720p25, 720p30
CVBS input Support
IP video input
2-ch
Up to 1080p resolution
Audio
compression
G.711u
Audio
input/Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC:
704 × 480
HDMI/VGA
output
1-ch, 1920 × 1080/60 Hz, 1280
× 1024/60 Hz, 1280 ×
720/60Hz, 1024 × 768/60 Hz
HDMI: 1-ch, 4K (3840 ×
2160)/30Hz, 2K (2560 ×
1440)/60Hz, 1920 × 1080/60
Hz, 1280 × 1024/60 Hz, 1280 ×
720/60Hz, 1024 × 768/60 Hz
VGA: 1-ch, 2K (2560 ×
1440)/60Hz, 1920 × 1080/60
Hz, 1280 × 1024/60 Hz, 1280 ×
720/60Hz, 1024 × 768/60 Hz

HIKVISION DS-7116HQHI-F1/N Specifications

General

Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Power consumption (typical)	20 W
Voltage	12 V
Product color	White
Rack capacity	1U
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Video input channels	16 channels
USB 2.0 ports quantity	2
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	1200 g
Dimensions (WxDxH)	285 x 210 x 45 mm
