HIKVISION DS-7116HQHI-F1/N User Manual

Digital Video Recorder User Manual
317
Sub-stream:
WD1/4CIF@12 fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate 32 Kbps to 10 Mbps
Audio output 2-ch, BNC (Linear, 1 KΩ)
Audio bit rate 64 Kbps
Dual stream Support
Stream type Video, Video & Audio
Synchronous
playback
8-ch 16-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP,
NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP
Hard disk
SATA 16 SATA interfaces
eSATA Support
Capacity Up to 8 TB capacity for each disk
External
interface
Two-way audio
input
1-ch, BNC (2.0 Vp-p, 1 KΩ) (independent)
Network
interface
2, RJ45 10M/100M/1000M self-adaptive Ethernet interface
USB interface
Front panel: 2 × USB 2.0
Rear panel: 2 × USB 3.0
Serial interface
1 RS-232 serial interface
1 RS-485 serial interface, full-duplex
1 RS-485 keyboard interface
Alarm in/out 16/8
General
Power supply 100 to 240 VAC
Consumption
(without HDD)
≤ 230 W

HIKVISION DS-7116HQHI-F1/N Specifications

General

Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Power consumption (typical)	20 W
Voltage	12 V
Product color	White
Rack capacity	1U
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Video input channels	16 channels
USB 2.0 ports quantity	2
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	1200 g
Dimensions (WxDxH)	285 x 210 x 45 mm
