HIKVISION DS-7216HQHI-F2/N User Manual

Digital Video Recorder User Manual
311
Model DS-8104HUHI-F8/N DS-8108HUHI-F8/N DS-8116HUHI-F8/N
Sub-stream:
WD1/4CIF@12fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit
rate
32 Kbps to 10 Mbps
Audio output 2-ch, RCA (Linear, 1 KΩ)
Audio bit
rate
64 Kbps
Dual-stream Support
Stream type Video, Video & Audio
Synchronous
playback
4-ch 8-ch 16-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI,
UPnP™, HTTPS, ONVIF, SNMP
Hard disk
SATA 8 SATA interfaces
eSATA Support
Capacity Up to 6 TB capacity for each disk.
External
interface
Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent)
Network
interface
2, RJ45 10M/100M/1000M self-adaptive Ethernet interface
USB
interface
Front panel: 2 × USB 2.0
Rear panel: 1 × USB 3.0
Serial
interface
RS-232, RS-485 (full-duplex), Keyboard
Alarm in/out 16/4
General
Power
supply
100 to 240 VAC

HIKVISION DS-7216HQHI-F2/N Specifications

General

Voltage	12 V
Certification	CE
Product color	White
Rack capacity	1U
Channels quantity	16 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	16
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	DC
Power consumption (max)	30 W

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	380 x 320 x 45 mm
