Digital Video Recorder User Manual
208
Enhanced VCA Mode: For DS-7200HUHI series DVR, the enhanced VCA mode conflicts with
the 2K/4K output and 4 MP/5 MP signal input. You can enable or disable VCA mode.
Enable Enhanced VCA Mode
1) Check the checkbox to enable enhanced VCA mode.
2) Click Apply and the attention box pops up as below.
Figure 16-4 Enable Enhanced VCA Mode (1)
Figure 16-5 Enable Enhanced VCA Mode (2)
3) Click Yes to apply the function and reboot the device.
Disable Enhanced VCA Mode
1) Uncheck the checkbox to disable enhanced VCA mode.
2) Click Apply and the attention box pops up as below.
Figure 16-6 Disable Enhanced VCA Mode (1)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7216HQHI-K2 and is the answer not in the manual?

HIKVISION DS-7216HQHI-K2 Specifications

General IconGeneral
Ethernet LANYes
Number of users128 user(s)
Ethernet interface typeGigabit Ethernet
Ethernet LAN (RJ-45) ports1
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Product colorBlack
Channels quantity16 channels
Maximum frame rate30 fps
Video capturing speed25 fps
Audio formats supportedG.711
Maximum video resolution1920 x 1080 pixels
Video compression formatsH.264, H.264+, H.265, H.265+
BNC input ports16
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
HDD interfaceSerial ATA
Maximum HDD capacity6000 GB
Number of HDDs supported2
Weight and Dimensions IconWeight and Dimensions
Weight2000 g
Dimensions (WxDxH)380 x 320 x 48 mm
