Digital Video Recorder User Manual
40
Step 4 After the time settings, click Next button to enter the General Network Setup Wizard
interface as shown below.
Figure 2-20 General Network Configuration
Step 5 Click Next button after you configured the basic network parameters.
Then you will enter the Hik-Connect interface. Configure the Hik-Connect according to your
need. Refer to Chapter 12.2.2 Configuring Hik-Connect for detailed operations.
Figure 2-21 Hik-Connect Configuration
Step 6 Click Next button to enter the Advanced Network Parameters interface. You can enable
DDNS and set other ports according to your need.

HIKVISION DS-7216HQHI-K2 Specifications

General

Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Product color	Black
Channels quantity	16 channels
Maximum frame rate	30 fps
Video capturing speed	25 fps
Audio formats supported	G.711
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
BNC input ports	16
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Number of HDDs supported	2

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	380 x 320 x 48 mm
