HIKVISION DS-7600NI-K1/W Series - Chapter 16 Appendix; Specifications

Network Video Recorder User Manual
201
Chapter 16 Appendix
16.1 Specifications
Model
DS-7804N-K1/W
DS-7808N-K1/W
Video/Audio
input
IP video input
4-ch
8-ch
Incoming bandwidth
50 Mbps
Video/Audio
output
HDMI/VGA output
1-ch, resolution: 1920 × 1080/60Hz, 1600 × 1200/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio output
1-ch, RCA (linear, 1 KΩ)
Decoding
Recording resolution
5M/4M/3M/1080p/1.3M/720p
Synchronous playback
4-ch
8-ch
Hard disk
SATA
1 SATA interface
Capacity
Up to 6 TB capacity for each disk
Wireless
parameters
Frequency band
2.4 GHz
Antenna structure
2*2MIMO. External antennas. PA and LNA modules are
supported.
Transmission speed
300 Mbps
Transmission standard
IEEE 802.11b/g/n
External
interface
Network interface
1, RJ45 100M Ethernet interface
USB interface
Rear panel: 2 × USB 2.0
General
Power supply
12 VDC
Consumption
(without HDDs)
≤ 18 W
Working temperature
-10 °C to +55 °C (14 °F to 131 °F)
Working humidity
10% to 90%
Dimensions
(W × D × H)
205 × 205 × 45 mm (8.1 × 8.1 × 1.8 in)
Weight (without HDDs)
≤ 1 kg (2.2 lb)
