User Manual of DS-7600NI Series NVR
52
Repeat the above steps to add more key points.
Click the icon to delete the corresponding key point, and click the trash icon to.delete all the key
points.
Select a key point, then click or button to adjust the order of the key points.
Figure 4. 8 Key Points Deletion
4.2.4 Calling Patrols
Purpose:
Calling a patrol makes the PTZ to move according the predefined patrol path.
Calling patrol in the PTZ setting interface:
Steps:
1. In the PTZ setting interface.
Menu> Camera> PTZ> More Settings
2. Select the patrol number, and then click to call the patrol.
3. Click to stop it.
Calling patrol in live view mode:
Steps:
1. Press PTZ control on the front panel or on the remote, or click PTZ Control icon on the quick setting
toolbar, to show the PTZ control toolbar.
2. Choose Patrol on the control bar.
3. Double click the patrol or select the patrol and click to call it.
