HIKVISION DS-7604 User Manual

24
• PTZ: Enter PTZ Control mode of the selected camera.
• Digital Zoom: Enter Digital Zoom interface of the selected camera.
• Menu: Enter Main menu.
• Start Auto-switch: Enable multi-camera sequence in Live View mode.
Note: The dwell time of the live view configuration should be set before using Start Auto-switch function.
Figure2. Live View Mouse Menu
Digital Zoom
To use digital Zoom in Live View mode:
1. Right-click the mouse in Live View mode.
2. Select Digital Zoom from drop-down submenu.
3. Left-click and drag the red box to the desired area for zooming. The zoomed image will be
magnified
by 4 times. An example is given in the following figure:
Figure3. Digital Zoom
Display
Click Menu >Settings >Display to access the Display settings:
www.cctvireland.ie
shop@cctvireland.ie

HIKVISION DS-7604 Specifications

General

Synchronous Playback	4-ch
Working Temperature	-10 °C to +55 °C (14 °F to 131 °F)
Operating Humidity	10% to 90%
Video Compression	H.264+, H.264
HDMI Output	1
VGA Output	1
Audio Output	1
Hard Disk	1 SATA interface
Network Interface	RJ45 10M/100M self-adaptive Ethernet interface
Network Protocols	TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SMTP, UPnP
USB Interface	2 x USB 2.0
Power Supply	12 VDC
Video Input	4-ch
