80
1. Enter the HDD Management menu by clicking Menu >HDD, select Advance tab, shown in
Figure 7.
Figure7. S.M.A.R.T Function
2. The checkbox of Enable S.M.A.R.T is already checked in default.
3. Select a HDD you want to view S.M.A.R.T information, the corresponding information will be
displayed below, shown in above figure.
4. If click to disable S.M.A.R.T function, the warning information appears, shown in Figure 9
Figure8. Warning Information Pop up
Configure HDD Alarms
HDD alarms can be set to trigger when an HDD is uninitialized or in an abnormal state.
To set HDD alarms:
1. Click Menu > Settings > Exception to enter Exception menu, shown in Figure9.
www.cctvireland.ie
shop@cctvireland.ie

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7604 and is the answer not in the manual?

HIKVISION DS-7604 Specifications

General IconGeneral
Synchronous Playback4-ch
Working Temperature-10 °C to +55 °C (14 °F to 131 °F)
Operating Humidity10% to 90%
Video CompressionH.264+, H.264
HDMI Output1
VGA Output1
Audio Output1
Hard Disk1 SATA interface
Network InterfaceRJ45 10M/100M self-adaptive Ethernet interface
Network ProtocolsTCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SMTP, UPnP
USB Interface2 x USB 2.0
Power Supply12 VDC
Video Input4-ch
