Page #17 background imageLoading...
Page #17 background image
www.hikvision.com/en/us
Stream Type allows enable/disable the audio streaming from the cameras (if the camera does not have
audio capabilities, then the Stream Type will only have Video option)
Resolution allows setting of the recording resolution
Bitrate Type allows the NVR to save HDD space when set to Variable (Available choses: Variable
and Constant)
Video Quality adjusts picture clarity (medium setting (3 green squares) is recommended. Medium
setting is the balance between good picture and saving HDD space).
Frame Rate allows setting of the recording frame rate (12-15 fps is recommended to save HDD space
and not to have a “choppy” image)
Max Bitrate Mode allows choosing between preset bitrate values and customizing the values
(General setting is recommended)
Max Bitrate (KBPS) is the chosen bitrate for streaming the video
Max Bitrate Recommended is the NVR’s recommended bitrate according to the parameters set
above.
Record Audio allows turning the audio recording on or off (this option is only available if the camera
has a microphone connected to it, or only the analog channels 1-4 on the hybrid NVR).
Video Stream allows changing the recording stream between Main Stream and Sub Stream (this step
requires a restart).
Please refer to the table below for recommended recording parameters
Resolution
Video Quality
Frame Rate (FPS)
Bitrate (KBPS)
320x240 (QVGA)
Medium (3 squares)
12-15
207
352x240 (CIF)
Medium (3 squares)
12-15
384
640x480 (VGA)
Medium (3 squares)
12-15
768
704x480 (4CIF)
Medium (3 squares)
12-15
1024
1280x720 (720P)
Medium (3 squares)
12-15
2048
1280x960 (960P)
Medium (3 squares)
12-15
2048
1600x1200 (2MP)
Medium (3 squares)
12-15
2560
1920x1080 (1080P)
Medium (3 squares)
12-15
3072
2048x1536 (3MP)
Medium (3 squares)
12-15
3072
2560x1920 (5MP)
Medium (3 squares)
8
4096
SETTING UP RECORDING

Other manuals for HIKVISION DS-7604NI-SE/P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7604NI-SE/P and is the answer not in the manual?

HIKVISION DS-7604NI-SE/P Specifications

General IconGeneral
Product colorBlack
Channels quantity4 channels
Playback resolutions supported5MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Audio input1
USB 2.0 ports quantity2
Ethernet LAN (RJ-45) ports5
Ethernet interface typeFast Ethernet, Gigabit Ethernet
HDD capacity1000 GB
HDD interfaceSerial ATA
Maximum HDD capacity4000 GB
Power consumption (typical)15 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Weight2000 g
Dimensions (WxDxH)445 x 290 x 45 mm
