Network Video Recorder User Manual
170
should be between 1 and 65535 and the value must be different from each other. If multiple devices are configured
for the UPnP™ settings under the same router, the value of the port No. for each device should be unique.
Figure 11. 29 External Port Settings Dialog Box
5. Click OK to save the setting for the current port and return to the upper-level menu.
6. Click Apply button to save the settings.
7. Enter the virtual server setting page of router; fill in the blank of Internal Source Port with the internal port
value, the blank of External Source Port with the external port value, and other required contents.
Each item should be corresponding with the device port, including server port, http port, RTSP port and https port.
Figure 11. 30 Setting Virtual Server Item
The above virtual server setting interface is for reference only, it may be different due to different router
manufactures. Please contact the manufacture of router if you have any problems with setting virtual server.
11.2.10 Configuring Virtual Host
Purpose:
You can directly get access to the IP camera management interface after enabling this function.
The Virtual host function can be only configured through the web browser.
Steps:
1. Enter the Advanced settings interface, as shown in the Figure 11. 31.
Configuration > Network > Advanced Settings > Other
To Next Page
