Page #29 background imageLoading...
Page #29 background image
Network Video Recorder Quick Start Guide
28
refer to the User Manual for activating the inactive IP camera.
You can select one of the following three options to add the IP camera.
OPTION 1:
Steps:
1. Click to select an idle window in the live view mode.
2. Click the icon in the center of the window to pop up the Add IP Camera interface.
Figure 3. 12 Add IP Camera
3. Select the detected IP camera and click the Add button to add it directly, and you can click the Search button
to refresh the online IP camera manually.
Or you can choose to custom add the IP camera by editing the parameters in the corresponding text field and
then click the Add button to add it.
3.9 Live View
Icons are provided on screen in Live View mode to indicate camera status. These icons include:
Live View Icons
In the live view mode, there are icons at the upper-right corner of the screen for each channel, showing the status
of the record and alarm in the channel for quick reference.
Alarm (video loss, tampering, motion detection, VCA or sensor alarm)
Record (manual record, continuous record, motion detection, VCA or alarm triggered record)
Alarm and Record
Event/Exception (event and exception information, appears at the lower-left corner of the screen.)

Other manuals for HIKVISION DS-7608NI-K1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7608NI-K1 and is the answer not in the manual?

HIKVISION DS-7608NI-K1 Specifications

General IconGeneral
Audio system2-way
Video codecsH.265/H.265+/H.264/H.264+/MPEG4
Input bandwidth80 Mbit/s
Maximum resolution1920 x 1080 pixels
Alarm input channels4
Video input channels8 channels
Alarm output channels1
Supported resolutions1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Output current1.8 A
Output voltage48 V
Power consumption (typical)10 W
Total Power over Ethernet (PoE) budget75 W
HDMI outputYes
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN (RJ-45) ports9
Supported network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity8
HDD capacity0 GB
HDD interfaceSATA, SATA II, SATA III
Maximum storage capacity6 TB
Number of HDDs installed0
Wi-FiNo
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
CertificationEN 301489-1, EN 301489-19, EN 301489-52, EN 303413, EN 301511, EN 301908-1, EN 301908-2, EN 301908-13, EN 62311:2008
Product colorBlack
Rack capacity1U
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width315 mm
Height48 mm
Weight1180 g
