User Manual of Digital Video Recorder
125
Default Route of the device should be in the same network segment as that of the LAN IP address of the router.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the UPnP tab to enter the UPnP interface.
Figure 9. 16 UPnP Settings Interface
3. Check checkbox to enable UPnP.
4. Select the Mapped Type as Manual or Auto in the drop-down list.
Task1: Auto
If you select Auto, the Port Mapping items are read-only, and the external ports are set by the router
automatically.
Steps:
1) Click to save the settings.
2) You can click to get the latest status of the port mapping.
Figure 9. 17 UPnP Settings Finished-Auto
Task2: Manual
If you select Manual as the mapping type, you can edit the external port on your demand by clicking
to activate the External Port Settings dialog box.
Steps:
1) Click to activate the External Port Settings dialog box. Configure the external port No. for
server port, http port, RTSP port and https port respectively.
Notes:
You can use the default port No., or change it according to actual requirements.
External Port indicates the port No. for port mapping in the router.
The value of the port No. should be between 1 and 65535 and the value must be different from each
other. If multiple devices are configured for the UPnP settings under the same router, the value of
