User Manual of Digital Video Recorder
173
13.3 Configuring More Settings
Steps:
1. Enter the General Settings interface.
Menu > Configuration > General
2. Click the More Settings tab to enter the More Settings interface.
Figure 13. 3 More Settings Interface
3. Configure the following settings:
• Device Name: Edit the name of device.
• Device No.: Edit the serial number of device. The Device No. can be set in the range of 1~255, and
the default No. is 255.
• CVBS Output Brightness: Adjust the video output brightness.
• Auto Logout: Set timeout time for menu inactivity. E.g., when the time is set to 5 Minutes, then
the system will exit from the current operation menu to live view screen after 5 minutes of menu
inactivity.
• Menu Output Mode: Set the menu output mode as Auto, HDMI/VGA or Main CVBS. E.g., when
HDMI/VGA is selected and HDMI/VGA output interface is connected, then the menu will be
displayed on HDMI/VGA monitor.
4. Click to save the settings.
