HIKVISION DS-7616HI-ST User Manual

User Manual of Digital Video Recorder
13
1.1 Front Panel
The front panel of the device is shown in Figure 1.1.
Figure 1. 1 Front Panel
Table 1. 1 Description of Front Panel
No.
Name
Function Description
1
POWER
POWER indicator turns green when device is powered up.
2
STATUS
STATUS indicator lights in red when data is being read from or written to
HDD.
3
Tx/Rx
Tx/Rx indictor blinks green when network connection is functioning properly.
4
IR Receiver
Receiver for IR remote.
5
USB Interface
Connects USB mouse or USB flash memory devices.
