User Manual of Digital Video Recorder
36
Figure 3. 2 Quick Setting Toolbar
Table 3. 4 Description of Quick Setting Toolbar Icons
Instant Playback only shows the record in last five minutes. If no record is found, it means there is no
record during the last five minutes.
Digital Zoom can zoom in the selected area to the full screen. You can left-click and draw to select the area
for zooming in, as shown in Figure 3.3.
Figure 3. 3 Digital Zoom
Image Settings icon can be selected to enter the Image Settings menu.
For Analog Cameras:
There are four preset modes for selection according to the real situation.
Below is the explanation for each mode.
Standard: for general lighting conditions (default).
Indoor: the image is relatively smoother.
Dim Light: the image is smoother than the other two modes.
Outdoor: the image is relatively clearer and sharper. The degree of contrast and saturation is high.
