HIKVISION DS-7616NI-K2 User Manual

Network Video Recorder User Manual
276
Capacity
Up to 6TB capacity for each disk
External
interface
Network
interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
USB interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm in/out
4/1
POE
Interface
Interface
8, RJ-45 10/100
Mbps
self-adaptive
Ethernet interface
16, RJ-45 10/100 Mbps self-adaptive
Ethernet interface
Power
≤ 120W
≤ 200W
Supported
standard
IEEE 802.3 af/at
General
Power supply
100 to 240 VAC, 50 to 60 Hz
Power
≤ 180 W
≤ 280 W
Consumption
(without hard
disk)
≤15 W (without enabling PoE)
Working
temperature
-10 to +55º C (+14 to +131º F)
Working
humidity
10 to 90 %
Chassis
385 mm chassis
Dimensions(W
× D × H)
385 × 315× 52 mm (15.2" × 12.4" × 2.0")
Weight(witho
ut hard disk)
≤ 3 kg (6.6 lb)

HIKVISION DS-7616NI-K2 Specifications

General

Input bandwidth	160 Mbit/s
Maximum frame rate	30 fps
Maximum resolution	3840 x 2160 pixels
Alarm input channels	4
Video input channels	16 channels
Alarm output channels	1
Supported resolutions	3840 × 2160, 2560 × 1440, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
HDMI output	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Output voltage	12 V
Power consumption (max)	40 W
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	0
Number of HDDs supported	2
Product color	Black
Rack capacity	1U
Wi-Fi	No

Weight and Dimensions

Depth	315 mm
Width	385 mm
Height	52 mm
Weight	1000 g
