HIKVISION DS-7716NXI-K4/16P User Manual

Figure 6-17 Alarm Output
2.
Click of a desired alarm output.
3.
Customize Alarm Name.
4.
Select Dwell Time.
Figure 6-18 Edit Alarm Output
5.
Set Sengs as Input to enable the funcon.
6.
Set the arming schedule. Refer to Congure Arming Schedule for details.
7.
Click Apply.
Flashing Light Alarm Output
When light and audio alarm camera is connected, you can set the ashing me, ashing frequency,
and arming schedule of the
ashing light alarm.
Before You Start
Light and audio alarm camera is connected.
Steps
1.
Go to Conguraon → Event → Normal Event → Flashing Light Alarm Output.
2.
Click for any row.
3.
Set the Flashing Time and Flashing Frequency.
4.
Set the arming schedule. Refer to
Congure Arming Schedule for details.
Network Video Recorder User Manual
66

HIKVISION DS-7716NXI-K4/16P Specifications

General

Model	DS-7716NXI-K4/16P
Video Input	16-ch
HDMI Output Resolution	4K (3840 × 2160)
VGA Output Resolution	1920 × 1080
Incoming Bandwidth	160 Mbps
Outgoing Bandwidth	256 Mbps
Two-Way Audio	Yes
Decoding Format	H.265+/H.265/H.264+/H.264
Alarm In/Out	16/4
PoE Ports	16
PoE Standard	IEEE802.3af/at
Working Temperature	-10°C to +55°C
Operating Temperature	-10°C to +55°C
Working Humidity	10% to 90%
Operating Humidity	10% to 90%
Chassis	1U Rackmount
Video Output	HDMI, VGA
Audio Output	1-ch, RCA
Decoding Capability	16 CH@1080P
HDD Capacity	Up to 10 TB per HDD
SATA Interfaces	4
Network Interface	1 × RJ45 10/100/1000 Mbps
USB Interface	2 × USB 2.0
Power Supply	100-240 VAC, 50/60 Hz
Weight	3.5 kg
