DS-K1100 Series Card Reader
5
4
5
3
1
Figure 1-12 Rear View of DS-K1104 Series
Table 1-1 Description of Rear View
No.
Name
1
Cable Interface of RS-485, Power, LED Control, etc.
2
Buzzer
3
Tamper-proof Module
4
DIP Switch
5
PSAM Card Slot (available for CPU card reader)
1.3 Slide View
The side view of card reader is shown below:
