HIKVISION DS-K1104MK User Manual

DS-K1100 Series Card Reader
12
1. Fix the gang box on the wall or
other place.
2. Connect the cables between
controller and card reader. For
details, refer to 2.4 Wiring
Cables.
3. Push the card reader to match
the fixed gang box.
4. Fasten the screw to keep the
components together.
5. Fix the side cover onto the card
reader, press the cover to make
it tightly fit the reader.

HIKVISION DS-K1104MK Specifications

General

Quantity per pack	1 pc(s)
Internal	No
Product color	Black, Silver
Built-in processor	Yes
Compatible memory cards	-
RS-485 ports	1
Type	Basic access control reader
Certification	FCC, CE
LED indicators	Status
RFID frequency	13.56 MHz
Authentication type	Access chip/card, Password
Supported protocols	Mifare
Keypad number of keys	12
RFID reading distance	50 mm
International Protection (IP) code	IP65
Operating temperature (T-T)	-20 - 65 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption	0.5 mA

Weight and Dimensions

Depth	23 mm
Width	76 mm
Height	118 mm
Weight	520 g
