7.4.5 Set Wiegand Parameters
You are able to set the Wiegand direcon (send/receive) and the Wiegand mode (Wiegand 26/
Wiegand 34).
Steps
1. Move the cursor and select Comm. → Wiegand .
2. Set the Wiegand parameters.
Direcon
Send
The device can connect to the access controller to upload the card No. bia the Wiegand 26
or the Wiegand 34 mode.
Receive
The terminal can connect to the Wiegand card readers. No need to congure the Wiegand
mode.
Mode
Wiegand 26 and Wiegand 34 can be selected. The default Wiegand mode is Wiegand 34.
Note
If you change the external device, and aer you save the device parameters, the device will
reboot automacally.
7.5 Person Management
7.5.1 Add Person
You can add users by seng the ID No., the user name, and the card No. You can also record the
user ngerprint, set the password, the department, the template, the role and the authencaon
mode.
Steps
1. Move the cursor and select User → New to enter the New page.
DS-K1T804B Series Fingerprint Access Control Terminal User Manual
22

HIKVISION DS-K1T804BEF Specifications

General

Model	DS-K1T804BEF
Type	IP Access Controller
Camera	2 MP
Communication	TCP/IP, RS-485
Power Supply	12 VDC/2 A
Dimensions	135mm × 105mm × 25mm (5.31" × 4.13" × 0.98")
Operation System	Linux
Fingerprint recognition duration	< 1s
FAR (False Acceptance Rate)	≤ 0.001%
Fingerprint comparing mode	1:1, 1:N
Fingerprint capacity	3000
Reading frequency	13.56 MHz
Card type	Mifare card
Working humidity	10% to 90% (non-condensing)
Installation	Wall-mounted
Language	Multi-language support
Reader Interface	Wiegand
Operating Humidity	10% to 90% (non-condensing)
Card Reader	Built-in card reader
Operating Temperature	-10 °C to +55 °C (14 °F to +131 °F)
Event capacity	100000
Working temperature	-10°C to 55°C (14°F to 131°F)
Communication Interface	RS-485
Wiegand Signal	Wiegand 26/34
