You can
congure the shi in the Shi Management. For detailed informaon, see Shi
Management .
By default, the system contains 32 departments.
Press the up or down key on the keypad to change the input method.
Search Department
Search the target department by entering the department name.
Move the cursor to the Dept., and press OK to enter the department list.
Enter the department name in the search box, and press OK to start search.
Reset Department
Reset all parameters of the target department to the default ones.
Move the cursor to the Dept., and press OK to enter the department list.
Select a department from the list and select Reset, and press OK. All parameters will be reset to
default ones.
7.8.3
Shi Management
The normal shi and the man-hour shi are available to be congured. You can set the aendance
rule and the aendance checking mes in the normal shi. You can also set the working hours per
day in the man-hour shi.
Normal Shi: It is applicable to the normal aendance situaon.
Man-Hour Shi: It is applicable to the situaon with exible working hours.
Set
Aendance Rule for Normal Shi
Move the cursor and select Shi → Normal → Rule , and press OK to enter the Rule page.
DS-K1T804B Series Fingerprint Access Control Terminal User Manual
39

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-K1T804BEF and is the answer not in the manual?

HIKVISION DS-K1T804BEF Specifications

General IconGeneral
ModelDS-K1T804BEF
TypeIP Access Controller
Camera2 MP
CommunicationTCP/IP, RS-485
Power Supply12 VDC/2 A
Dimensions135mm × 105mm × 25mm (5.31" × 4.13" × 0.98")
Operation SystemLinux
Fingerprint recognition duration< 1s
FAR (False Acceptance Rate)≤ 0.001%
Fingerprint comparing mode1:1, 1:N
Fingerprint capacity3000
Reading frequency13.56 MHz
Card typeMifare card
Working humidity10% to 90% (non-condensing)
InstallationWall-mounted
LanguageMulti-language support
Reader InterfaceWiegand
Operating Humidity10% to 90% (non-condensing)
Card ReaderBuilt-in card reader
Operating Temperature-10 °C to +55 °C (14 °F to +131 °F)
Event capacity100000
Working temperature-10°C to 55°C (14°F to 131°F)
Communication InterfaceRS-485
Wiegand SignalWiegand 26/34
