HIKVISION DS-KD-KP User Manual

2. Set the sub module address according to the DIP rules, and
install the rubber cover back.
Note
●
DIP 1, 2, 3, 4 are used to coding the sub module address. DIP
5, 6, 7, 8 are reserved.
●
Valid sub module address is from 1 to 8. The address should
be unique for connecng to the main unit.
The sub module address and its corresponding switch status
are displayed as below.
Sub
Modul
e
Addre
ss
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
Modul
e 1
ON OFF OFF OFF OFF OFF OFF OFF
Modul
e 2
OFF ON OFF OFF OFF OFF OFF OFF
Modul
e 3
ON ON OFF OFF OFF OFF OFF OFF
Modul
e 4
OFF OFF ON OFF OFF OFF OFF OFF
Modul
e 5
ON OFF ON OFF OFF OFF OFF OFF
Modul
e 6
OFF ON ON OFF OFF OFF OFF OFF
Modul
e 7
ON ON ON OFF OFF OFF OFF OFF
Modul
e 8
OFF OFF OFF ON OFF OFF OFF OFF
4.2 Two-Module Installaon
4.2.1 Two-Module Surface Mounng
13

HIKVISION DS-KD-KP Specifications

General

IK code	IK07
Product type	Keypad
Mounting type	Surface
Product color	Black, Grey
Brand compatibility	Hikvision
International Protection (IP) code	IP65
Package weight	529 g
Quantity per pack	1 pc(s)
Storage temperature (T-T)	10 - 95 °C
Operating temperature (T-T)	-40 - 55 °C
Sustainability certificates	RoHS, WEEE, REACH
DC input voltage	12 V

Weight and Dimensions

Depth	33.7 mm
Width	98.5 mm
Height	100 mm
Weight	265 g
