Note
•
The dimension of the g
ang box is 364 mm (W) × 118 mm (H) × 40 mm (D).
•
The
installaon hole should be bigger than the actual size. The suggested
dimension of the installaon hole is 364.3 mm (W) × 118.6 mm (H) × 40.2 mm
(D).
3.2 Flush Mounng with Gang Box
Steps
1.
Ca
ve an installaon hole in the wall. Pull the cable out from the wall.
Note
•
The sug
gested dimension of the installaon hole is 364.3 mm (W) × 118.6
mm (H) × 40.2 mm (D).
•
The sug
gested length of the cables le outside is 250 mm.
2.
Ins
tall the gang box into the wall.
1) Remove the plasc sheet of the gang box with the tool.
2)
Insert the gang box into the installaon hole. Mark the gang box screw holes'
posion with a marker, and take out the gang box.
3) Drill 4 holes according to the marks on the wall, and insert the expansion
sleeves into the screw holes.
4) Fix the gang box with 4 expansion bolts.
3.
Fix the gap between the gang box and wall with concrete. Remove the mounng
ears with tool aer concrete is dry. Connect the cables according to the Wiring
Descripon.
4.
Insert the door
staon into the gang box. Slide the door staon down and x it
with 2 set screws. Apply Silicone sealant among the joints between the device
and the wall (except the lower side) to keep the raindrop from entering.
Video Intercom Face Recognion Door Staon with 4.3-inch Screen User Manual
9
