Video Intercom Demo Case·User Manual
8
Figure 3-1 Calling from Door Station
 Tap to answer the call, and tap to reject the call.
 Tap Unlock tab or the button to unlock the door.
 Tap tab to capture the snapshots.
3.2 Video Intercom Function of Group 3
For group 3, there are 5 modules of door station and 3 accessory packages.
You can replace the modules in the group 1 of modules in group 2.
3.2.1 Call Resident
You can call corresponding resident in two ways:
1. Press the call button on the main unit or on the nametag module.
2. Enter the Room No. on the keypad module, and press # key to start calling.
(Press * to hang up.)

HIKVISION DS-KH8350-WTE1 Specifications

General

Product color	Black
Package weight	899 g
Indoor unit included	Yes
Outdoor unit included	No
Display diagonal	7 \
Display resolution	1024 x 600 pixels
Operating system installed	Linux
Voice codecs	G.711u
Number of speakers	1
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE, UL, CB, RCM
Connectivity technology	Wired & Wireless
Maximum number of cameras supported	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, SIP, RTSP
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Power consumption	200 mA
Indoor unit power type	DC
Power consumption (typical)	7 W
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Weight	355 g
Door station dimensions (WxDxH)	180 x 140 x 22.4 mm
