HIKVISION DS-KH8350-WTE1 User Manual

Video Intercom Demo Case·User Manual
3
2 Getting Started
2.1 Activate Indoor Station
You can only configure and operation the device after creating a password for the device
activation.
Steps:
1. Power on the device. It will enter the activation page automatically.
2. Create a password and confirm it.
3. Tap OK to activate the indoor station.
We highly recommend you to create a strong password of your own choosing
(using a minimum of 8 characters, including at least three kinds of following
categories: upper case letters, lower case letters, numbers, and special characters)
in order to increase the security of your product. And we recommend you reset
your password regularly, especially in the high security system, resetting the
password monthly or weekly can better protect your product.
2.2 Quick Operation
For DS-KH8350-WTE1 and DS-KH6320-WTE1, after device activation, the wizard page
will pop up.
Steps:
1. Choose language and tap Next.
Figure 2-1 Wizard-Language Settings
2. Set network parameters and tap Next.

HIKVISION DS-KH8350-WTE1 Specifications

General

Product color	Black
Package weight	899 g
Indoor unit included	Yes
Outdoor unit included	No
Display diagonal	7 \
Display resolution	1024 x 600 pixels
Operating system installed	Linux
Voice codecs	G.711u
Number of speakers	1
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE, UL, CB, RCM
Connectivity technology	Wired & Wireless
Maximum number of cameras supported	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, SIP, RTSP
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Power consumption	200 mA
Indoor unit power type	DC
Power consumption (typical)	7 W
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Weight	355 g
Door station dimensions (WxDxH)	180 x 140 x 22.4 mm
