HIKVISION DS-KH8350-WTE1 User Manual

Video Intercom Demo Case·User Manual
12
4 Live View
For network indoor stations, you can get the live view of the added door stations on the
live view page of the indoor station.
Before you start:
 Make sure both the door station and the indoor stations are well-connected.
 Make sure the door station and the indoor stations have been activated.
Steps:
1. Add the same door station to the 2 indoor stations.
1) Tap Settings -> -> Configuration, and input the configuration password to
enter the configuration page.
The default configuration password is 888999.
2) Tap to enter the device management page.
3) Tap Main Door Station, select the main door station type as Main Door Station,
and input the IP of the door station.
The default IP of the door station in the demo case is 192.0.0.70.
2. On the home page, and tap Live View tab to enter the live view page.
Figure 4-1 Live View Page
3. Tap -> Main Door Station to get the live view of the door station.

HIKVISION DS-KH8350-WTE1 Specifications

General

Product color	Black
Package weight	899 g
Indoor unit included	Yes
Outdoor unit included	No
Display diagonal	7 \
Display resolution	1024 x 600 pixels
Operating system installed	Linux
Voice codecs	G.711u
Number of speakers	1
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE, UL, CB, RCM
Connectivity technology	Wired & Wireless
Maximum number of cameras supported	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, SIP, RTSP
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Power consumption	200 mA
Indoor unit power type	DC
Power consumption (typical)	7 W
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Weight	355 g
Door station dimensions (WxDxH)	180 x 140 x 22.4 mm
